您當前所在位置:網站首頁 > 產品中心 > YMQ-商標模切機
產品詳情
主要產品有YMQ系列商標模切機、SJQ系列切角機、SWY目錄索引挖月機、YP系列書芯壓平機、YYJ書背壓緊機及其它

YMQ-260型商標模切機

YMQ系列沖切抹角機主要針對各種異形商標,如各類食品、飲料標鑒的成型模切,還可廣泛應用于裁切各種大小的克牌、鋁塑袋、賀年卡、方便面蓋、筆記本 、吊牌、小冊子等,以及各種特殊形狀的兒童讀物卡片書籍。

??YMQ系列沖切抹角機主要針對各種異形商標,如各類酒、食品、飲料標鑒的成型模切,還可廣泛應用于裁切各種大小的撲克牌、鋁塑袋、賀年卡、方便面蓋、筆記本、吊牌、小冊子等,以及各種特殊形狀的兒童讀物卡片書籍。

??本機采用液壓系統,工作穩定可靠、模切成品表面光潔,尺寸統一、整齊,效率更高;左右各有光電眼,使用更安全;裝料平臺可以進行左右前后與整體調節,使用更加方便。

YMQ series punching and wiping angle machine is mainly used for cutting all kinds of special-shaped trademarks, such as all kinds of wine, food and beverage labels, and can also be widely used for cutting all kinds of playing cards, aluminum plastic bags, greeting cards, instant noodle covers, notebooks, credit cards, tags, brochures and other special shapes of children's reading card books.

 The machine adopts the hydraulic system, which is stable and reliable, the surface of die-cut products is bright and clean, the size is uniform, neat, and the efficiency is higher; there are photoelectric eyes on the left and right, which is safer to use; the loading platform can be adjusted before and after the left and right and as a whole, which is more convenient to use.



YMQ-260型型商標模切機

??沖切抹角機YMQ-260技術參數


型號

Model

YMQ-260

極大模切尺寸

Max.Die-cut size

290x290300x240)(mm

極小模切尺寸

Min. Die-cut size

65x65mm

極大模切厚度

Max.Die-cut height

260mm

活塞桿直徑

Piston rod diameter

Φ80mm

流量

flow

37 L/min

模切壓力

Die-cut pressure

8T

工作速度

Working speed

65mm/s

電機功率

Power

7.5HP/5.6KW

工作電壓

Voltage

380V

包裝外形尺寸

Overall dimension[mm]

2430x1000x1780mm

整體重量

Weight of whole machine

1600kg


<>
